Model

POS-1519

Name

15.1 inch all in one touch POS terminal

Housing

Platic shell machine body and aluminium base

Color

whole black color machine

Main screen

15.1 inch touch screen monitor

Resoluiton

1024*768

Brightness

250cd/m2

View angle

Horizon: 150; Vertical :140

Touch screen

Multi-point projected G+G capacitive touch

Sub-display

10.1-inch display

Performance

Motherboard

 intel core I5 CPU

System Memory

Storage device

Msata SSD 128GB

Audio

On board Real Tek ALC662

LAN

10/100Mbs,Realtek RTL8111F Lan chip

built in Mini PCI-E slot,support embedded WIFI module

Operating System

Windows 10

Connectivity

External

I/O port J4125

power button*1,12V DC in Jack*1

LAN:RJ-45*1

USB*6

15PIN D-sub VGA *1

RS 232*2

line out*1,MIC in*1

Options

MSR

Optional side MSR

Package

Weight

Net 6.5Kg, Gross 8.0Kg for single screen

Package with foam inside

425*275*405mm for single screen, 440*295*425mm for dual screen

Environment

Operating temperature

0 to 40 degrees centigrade

Storage temperature

-10 to 60 degrees centigrade

Working humidity

10%~80%    No condensation

Storage humidity

10%~90%    No condensation

Accessories

Power adapter

200-240V/50-60HZ(default) , 110-240V/50-60HZ AC power input, DC12V/5A output adaptor

Power cable

Power cable plug compatible with USA /EU / UK
